10m Platform Height 230kg Load Self Propelled Scissor Lift with Extension Platform
1. Self propelled scissor lift ,with automatic walking function, can be in different work condition, do not need external power supply, do not need artificial traction.
2. Mobile flexible, convenient operation, lift freely, only one people can finish forward, backward, steering, fast and slow walk ,easily moved, spacious working platforms, high working efficiency.
3. Scissor lift can be move while extended and controlled from platform by the operator.
4. Most models are equipped with zero inside turning radius capability, can be easily and flexibly operated in crowed working conditions such as construction site,elevator, and narrow corridor. Lift-down,turning, forward and backward movements can be easily operated by one person.
Specification
| Model | MX580S | MX600SN | MX800SN | MX800S | MX1000S | MX1200S |
| Load | 230 kg | 230 kg | 230 kg | 450 kg | 320 kg | 230 kg |
| Extension Load | 113 kg | 113 kg | 113 kg | 113 kg | 113 kg | 113 kg |
| Platform Height | 5.8 m | 6 m | 8 m | 8 m | 10 m | 11.8 m |
| Working Height | 7.8 m | 8 m | 10 m | 10 m | 12 m | 13.8 m |
| Platform Size | 1.67*0.74m | 2.27*0.81m | 2.27*0.81m | 2.27*1.12m | 2.27*1.12m | 2.27*1.12m |
| Platform Extension Length | 0.9 m | 0.9 m | 0.9 m | 0.9 m | 0.9 m | 0.9 m |
| Lift/Drive Motor | 24v/3.3 kw | 24v/3.3 kw | 24v/3.3 kw | 24v/3.3 kw | 24v/3.3 kw | 24v/4.5 kw |
Safety Precaution
- Auxiliary Lowering Devices
- Anti-burst System
- Emergency Stop Button
- Tilting Protection System
- Charging Protection System
- Automatic Pothole Protection
- Automatic Braking System
- Buzzer and Horn
Our Company
Factory Equipments
Our Certificates
Our Clients
Other Related Products
Our Service
1. We can design the customized the machines based on your requirement.
2. After knowing your detailed need, the right models will be recommened to you with good price.
3. Shipment can be arranged from our port to your destination port.
4. Opetion video can be sent to you if needed.
5. Parts of machines can be sent to you by express within 7 days if needed.
